12/20(24)kV XLPE insulation Power Cable
Application：
Our mains power distribution cables with a voltage rating of 12/20kV are commonly used in European installations, laid direct in the ground, outdoors and indoors.
Model No.：12/20(24)kV XLPE insulation Power Cable
Voltage: 12/20(24)kV
Conductor： Copper/Aluminum
Insulation： XLPE
Screen：Copper wire and Copper tape
Sheath：PVC
Armor：with or without
Sheath：PVC
Brand：KINGYEAR
Standard：ASTM B3/B8,UL 83,UL 1277
Place of Origin：China
Package：Exported Wooden Drum or soft roll
Range of Application：Power Cable
Terms of Payment: L/C, T/T, D/P, PayPal, Western Union, Small-amount payment
Production Capacity：30000m/week
Conductor: Stranded Aluminium/Copper Conductor
Inner Screen: Semi Conductive Compound
Insulation: Cross Linked Polyethylene (XLPE)
Core Screen: Semi Conductive Compound
Outer Screen: Copper Wire Screen & Counter Helix Copper Tape
Sheath: PVC
Sheath Colour: Black
KINGYEAR Cables' range of 20kV cables generally have a single conductor and employ copper wires as an electromagnetic screen to prevent interference with other cables sited nearby. Where required, the cables are available with water swellable powders or tapes and bonded foil tapes for a longitudinal watertight layer to protect against the damaging effects of water in the insulation system, which has the potential to bring on the premature onset of partial discharge and reduce the life of the cable.
KINGYEAR from 2013-2018 are mainly for domestic trading and processing to some export trading companies. The average sales amount are about RMB 320,000,000 per year. For cables oversea market, From last may till now we have expanded our market to Bolivia, Peru, Dominican, Philippines, Vietnam, Thailand, Iraq, Mongolia, Indonesia and some Africa country. With total sales amount over USD10,000,000.
