Irrigation System Cable
Application：
Type Irrigation cable is designed to operate electric motor driven irrigation systems .Type Irrigation Cable is rated 75ºC and permitted for 600V application.
Model No.： Irrigation System Cable
Material：Copper
Brand：KINGYEAR
Standard：IEC/ASTM/GBT/BS/DIN/EN
Place of Origin：China
Package：Exported Wooden Drum
Range of Application：Irrigation System
Terms of Payment: L/C, T/T, D/P, PayPal, Western Union, Small-amount payment
Certification：ISO,CE and other certifications.
Production Capacity：30000m/week
Conductors: Soft annealed stranded copper ,bare or coated.
Insulation: XLPE/PVC
Sheath: XLPE/PVC
Individual conductors are bare annealed copper covered with a polyvinyl chloride (PVC) insulation over which a nylon (polyamide) or UL listed equal jacket is applied. The overall jacket consists of a heat, moisture and sunlight resistant PVC. Non-halogen jacket available upon request. Overall PVC Jacket. Heat, Moisture and Sunlight Resistant
KINGYEAR from 2013-2018 are mainly for domestic trading and processing to some export trading companies. The average sales amount are about RMB 320,000,000 per year. For cables oversea market, From last may till now we have expanded our market to Bolivia, Peru, Dominican, Philippines, Vietnam, Thailand, Iraq, Mongolia, Indonesia and some Africa country. With total sales amount over USD10,000,000.
Specifications
|
Size AWG |
PVC Inner Jacket Average Thickness (mm) |
Aluminum Shield Thickness (mm) |
Approx. O.D. (mm) |
Approx. Weight (kg/km) |
|
14/4 |
0.76 |
0.25 |
12.9 |
196.04 |
|
12/4+16/7 |
0.76 |
0.25 |
17.2 |
397.16 |
|
12/4+14/7 |
0.76 |
0.25 |
18.2 |
462.38 |
|
10/4+14/7 |
0.76 |
0.25 |
19.9 |
563.55 |
|
14/4+18/6 |
0.76 |
0.25 |
16.7 |
288.61 |
|
12/4+14/6 |
0.76 |
0.25 |
18.0 |
432.50 |
|
10/4+14/6 |
0.76 |
0.25 |
19.7 |
534.97 |
