Rubber cable
Application：
This cable is primarily used in all kinds of electrical equipment, such as the mobile power of household appliances, electric machinery,
electrical equipment and tools, and it is also can be used in indoor or outdoor enviroment conditions.
Model No.： Rubber cable
Material：Copper/rubber/rubber
Brand：KINGYEAR
Standard：ASTM/IEC/AS/GBT/BS
Place of Origin：China
Package：soft roll or drum
Range of Application：indoor
Terms of Payment: L/C, T/T, D/P, PayPal, Western Union, Small-amount payment
Certification：ISO,CE and other certifications.
Production Capacity：30000m/week
A combination of robustness and flexibility makes rubber cables ideal to provide power supply to portable electrical equipment and devices. The mechanical stresses involved in moving apparatus require cables to withstand a high degree of wear-and-tear. Our HOFR (heat & oil resistant and flame-retardant) the cables are designed to withstand extreme weather, oil/grease, mechanical as well as thermal stresses, also using compounds such as Ethylene Propylene Rubber (EPR) and Chlorosulphonated Polyethylene (CSP) as insulating materials. These flexible rubber cables are suitable for a wide range of applications including mobile power supplies, light and heavy duty equipment, and submersible pumps, as welding cables providing power from the machine to the tool, for audio visual equipment, and equipment on construction sites.
These cables are made with synthetic rubbers having an excellent temperature resistance and can be used either in dry, humid or wet places or in contact with oil or grease, in weather conditions and under medium mechanical stress, for example power supply to equipment in industrial plants, large size boilers, heating plates, portable lamps, electrical tools such as drilling machines, disk saws, portable engines and machines, building and farming equipments etc.
These cables are also suitable for stationary equipments, for example designed for wind-tower application, the particular conductor Cable Construction and the used materials have improved the cable torsion resistance (max 150°/m), key requirement for drop cables in windgenerators, on plaster in temporary buildings and builders huts, and wiring in machinery elevators or similar.
Suitable for caravans and camping equipment. Especially recommended for service temperature up to 90oC together with good resistance to hot grease and oil. Therefore these cables are ideal for use in plants and industries dealing with grease, oil or oil emulsion treatments, transformation or handling.
KINGYEAR from 2013-2018 are mainly for domestic trading and processing to some export trading companies. The average sales amount are about RMB 320,000,000 per year. For cables oversea market, From last may till now we have expanded our market to Bolivia, Peru, Dominican, Philippines, Vietnam, Thailand, Iraq, Mongolia, Indonesia and some Africa country. With total sales amount over USD10,000,000.
Specifications
|
HAR Code |
IEC |
Description |
Voltage Design |
Cores |
|
H05RR-F |
60245 IEC 53(YZ)/YZ |
Oridinary rubber sheathed flexibale rubber cable |
300/500V |
2~5 |
|
H05RN-F |
60245 IEC 57(YZW)/YZW |
Oridinary polychloroprene or other equivalent synthetic elastomer sheathed flexible rubber cable |
300/500V |
2~5 |
|
H07RN-F |
60245 IEC 66(YCW)/YC |
Heavy polychloroprene or other equivalent synthetic elastomer sheathed flexible cable |
450/750V |
1~5 |
