Application：

The H1Z2Z2-K Cable for Industrial Use provides a flexible and insulated wiring solution for photovoltaic power supply systems at nominal voltage rates up to 1.5/1.5kV DC. It is suitable for indoor and outdoor use in industrial and agriculture fields, as well as in equipment with protective insulation and in explosion hazard areas. The cable may be installed fixed, freely suspended, or free movable, in cable trays, conduits, on and in walls.

Model No.：H1Z2Z2-K Cable

Voltage: DC:1.5/1.5kV,AC:1.0/1.0kV

Conductor： Class 5 Aluminum alloy/Tinned Copper

Insulation： Halogen-free cross-linked LS0H-XL compound,Black

Sheath： Halogen-free cross-linked LS0H-XL compound,Black or Red

Brand：KINGYEAR

Standard：ASTM B3/B8,UL 83,UL 1277

Place of Origin：China

Package：Exported Wooden Drum or soft roll

Range of Application：Solar Cable

Terms of Payment: L/C, T/T, D/P, PayPal, Western Union, Small-amount payment

Production Capacity：30000m/week

Inquiry

Write a Review

CONSTRUCTION

 Conductor : Flexible tinned copper class 5 (K) as per EN 60228

 Insulation:Halogen-free cross-linked LS0H-XL compound,Black

 Outer sheath: Halogen-free cross-linked LS0H-XL compound,Black or Red

Rated voltage

DC: 1,5/1,5 kV

AC: 1,0/1,0 kV

Max. permissible operating voltage:

AC 1,2/1,2 kV

DC 1,8/1,8 kV

Test voltage

AC: 6,5 kV / DC: 15 kV (5 min)

Minimum bending radius

Fixed installation approx. 4 x outer diameters

Flexing 10 x cable diameter

Temperature range

Operating temperature: -40°C to +90°C

Max. conductor temperature: 120°C

Specifications

Advantage

Customization

Providing tailored designs to meet specific requirements.

After-Sales Service

Ensuring continuous support and satisfaction post-purchase.

Timely Delivery

Committing to prompt and reliable delivery schedules.

Training and Documentation

Providing detailed documentation for easy operation and maintenance.

FAQ

Q:I didn't find the product which I need in this page?

A:If you didn't find the species of the produxts you need, please contact us directly, we will reply you quickly.

Q:What's your minimum order quantity?

A:It is not so sure, you can confirm it with us. Normally, it will be 5 tons.

Q:What's your delivery time?

A:It depends on whether we just has the stock for your type.Normally,it takes about 7-15days to achieve production.

Q:How can I get a sample from your company? Is the sample free?

A:If you need the sample to check the quality, please contact us, we will send you the free sample, but the freight charge should be paid.

Q:What if the product which we need have some differences on specifications from yours?

A: Any difference, we can design and produce according to your requests, which include size, color, material, processing requirement etc.
